Iris & Oculus Flywheel Compat

The version 2.0.3 now fully supports Create 6.0.

What's this?

• Flywheel will disable its optimizations when you are using shaderpacks.
• This mod forces Flywheel’s optimizations to be enabled.
• For those using shaderpacks and mods that depend on Flywheel, this mod can significantly improve fps.
• If you don’t use shaderpacks, this mod has no effect because Flywheel’s optimizations are enabled by default.

Compatibility

The shaders that have been tested are:

• BSL
• Complementary
• Complementary Reimagined
• SEUS renewed
• Sildurs Vibrant Shaders
• AstraLex
• Kapa 5.1
• Nostalgia
• Rethinking Voxels
• SEUS PTGI HRR

There are some shaderpacks that are also supported, but not listed above, so you can test them yourself.

This mod only supports some specific versions of Iris !!!

IrisFlwCompat    Iris

2.0.3                   >=1.8.1

0.2.5                   >=1.7

0.2.0                   >=1.6.2

0.1.9                   >=1.5 and

0.1.7~0.1.8         >=1.4 and

0.1.6 below

CHANGELOG

2024/7/28

Principle

Flywheel uses a method called GPU Instancing to render entities. It is very efficient when rendering a large number of repeating entities (e.g., cogwheels in the Create mod).

However, when you use Iris and enable shaderpack, this optimization is disabled because Flywheel needs to use its own shaders to render these entities, and Flywheel’s shaders will no longer work when you enable shaderpack.

This mod will automatically merge Flywheel’s shaders with the shaders in the shaderpack when shaderpack is enabled, allowing entities to be rendered using Instancing.

When there is a large number of entities to render, there is a significant CPU bottleneck with the original rendering method. This means that the better your GPU is, the more substantial the FPS improvement from Flywheel will be. For example, on my RTX 4070ti at 4K resolution, the scene in the screenshot improved from 26fps to 65fps.

How to use it?

1. Install Flywheel(Create has embedded flywheel so you don't need to install it separately now) and Iris (Oculus if you use forge).

2. Install this mod.
